User's Manual 580 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
• Endpoints per Trunk Group: Open the Trunk Group Settings table (see
''Configuring Trunk Group Settings'' on page 467), and then for the required
Trunk Group ID, configure the 'Registration Mode' parameter to Per Endpoint
(TrunkGroupSettings_RegistrationMode).
2. Open the Authentication table (Setup menu > Signaling & Media tab > Gateway
folder > Analog Gateway > Authentication).
3. Select the row corresponding to the port that you want to configure, and then click
Edit; the following dialog box appears:
Figure 27-5: Authentication Table - Edit Dialog Box
4. Configure authentication per port according to the parameters described in the table
below.
5. Click Apply.
Table 27-1: Authentication Table Parameter Descriptions
Parameter Description
General
Index
[Authentication_Index]
(Read-only) Displays the index number of the table row.
Module
port-type
[Authentication_Module]
(Read-only) Displays the module number on which the port is
located.
Port
port
[Authentication_Port]
(Read-only) Displays the port number.
Port Type
[Authentication_PortType]
(Read-only) Displays the port type (FXS or FXO).
Credentials
User Name
user-name
[Authentication_UserId]
Defines the user name used for authenticating the port.
Password
password
[Authentication_UserPassword]
Defines the password used for authenticating the port.
