AudioCodes MediaPack MP-11 Series User Manual

Version 7.2 653 Mediant 1000B Gateway & E-SBC
User's Manual 33. Routing SBC
Parameter Description
of SIP Dialog Requests'' on page 609.
The default is the asterisk (*) symbol, which represents any source
host prefix.
Note: For REGISTER requests, the source URI is obtained from the
To header.
Destination Username Prefix
dst-user-name-prefix
[Classification_DestUsernam
ePrefix]
Defines the prefix of the destination Request-URI user part as a
matching characteristic for the incoming SIP dialog.
The default is the asterisk (*) s
ymbol, which represents any destination
username. The prefix can be a single digit or a range of digits. For
available notations, see ''Dialing Plan Notation for Routing and
Manipulation'' on page
923.
Destination Host
dst-host
[Classification_DestHost]
Defines the prefix of the destination Request-URI host name as a
matching characteristic for the incoming SIP dialog.
The default is the asterisk (*) symbol, which represents any destination
host prefix.
Message Condition
message-condition-name
[Classification_MessageCon
ditionName]
Assigns a Message Condition rule to the Classification rule as a
matching characteristic for the incoming SIP dialog.
By default, no value is defined.
To configure Message Condition rules, see ''Configuring Message
Condition Rules'' on page 655.
Action
Action Type
action-type
[Classification_ActionType]
Defines a whitelist or blacklist for the matched incoming SIP dialog.
 [0] Deny = Blocks incoming SIP dialogs that match the
characteristics of the rule (blacklist).
 [1] Allow = (Default) Allows incoming SIP dialogs that match the
characteristics of the rule (whitelist) and assigns it to the associated
IP Group.
Destination Routing Policy
dest-routing-policy
[Classification_DestRouting
Policy]
Assigns a Routing Policy to the matched incoming SIP dialog.
The assigned Routing Policy overrides the Routing Policy assigned to
the SRD (in the SRDs table). The option to assign Routing Policies to
Classification rules is useful in deployments requiring different routing
and manipulation rules for specific calls pertaining to the same SRD.
In such scenarios, you need to configure multiple Classification rules
for the same SRD, where for some rules no Routing Policy is assigned
(i.e., the SRD's assigned Routing Policy is used) while for others a
different Routing Policy is specified to override the SRD's assigned
Routing Policy.
By default, no value is defined.
To configure Routing Policies, see ''Configuring SBC Routing Policy
Rules'' on page 670.
Source IP Group
src-ip-group-name
[Classification_SrcIPGroupN
ame]
Assigns an IP Group to the matched incoming SIP dialog.
By default, no value is defined.
To configure IP Groups, see ''Configuring IP Groups'' on page 333.
Note: The IP Group must be associated with the assigned SRD (see
the 'SRD' parameter in the table).
IP Profile Assigns an IP Profile to the matched incoming SIP dialog.
The assigned IP Profile overrides the IP Profile assigned to the IP
