Version 7.2 847 Mediant 1000B Gateway & E-SBC
User's Manual 54. Reporting Information to External Party
CDR Field Description CDR Report Type
(SBCReportType)
Format
DirectMedia
Direct media or traversing SBC:
 "yes"
 "no"
All String
SIPTrmReason
SIP call termination reason (BYE,
CANCEL, or SIP error codes, e.g., 404)
"CALL_END" String (up to
12
characters)
SipTermDesc
Description of SIP termination reason:
 SIP Reason header, if exists, for
example: SIP ;cause=200 ;text="Call
completed elsewhere".
 If no SIP Reason header exists, the
description is taken from the reason
text, if exists, of the SIP response
code, for example: "417 Unknown
Resource-Priority".
 If no reason text exists in the SIP
response code, the description is taken
from an internal SIP response mappi
mechanism. For example, if the device
receives a SIP response "422", it
sends in the CDR "422 Session
Interval Too Small method" as the
description.
"CALL_END" String (up to
26
characters)
Caller
Name of caller All String (up to
36
characters)
Callee
Name of called party All String (up to
36
characters)
Below shows an example of an SBC signaling CDR sent at the end of a call (call was
terminated normally):
[S=40] |SBCReportType |EPTyp |SIPCallId |SessionId |Orig |SourceIp
|SourcePort |DestIp |DestPort |TransportType |SrcURI
|SrcURIBeforeMap |DstURI |DstURIBeforeMap |Durat |TrmSd |TrmReason
|TrmReasonCategory |SetupTime |ConnectTime |ReleaseTime
|RedirectReason |RedirectURINum |RedirectURINumBeforeMap
|TxSigIPDiffServ|IPGroup (description) |SrdId (name)
|SIPInterfaceId |ProxySetId |IpProfileId (name) |MediaRealmId
(name) |DirectMedia |SIPTrmReason |SIPTermDesc |Caller |Callee
[S=41] |CALL_END |SBC |20767593291410201017029@10.33.45.80
|1871197419|LCL |10.33.45.80 |5060 |10.33.45.72 |5060 |UDP
|9001@10.8.8.10 |9001@10.8.8.10 |6001@10.33.45.80
|6001@10.33.45.80 |15 |LCL |GWAPP_NORMAL_CALL_CLEAR
|NORMAL_CALL_CLEAR |17:00:29.954 UTC Thu Oct 14 2014
|17:00:49.052 UTC Thu Oct 14 2014 |17:01:04.953 UTC Thu Oct 14
2014 |-1 | | |40 |1 |0 (SRD_GW) |1 |1 |1 () |0 (MR_1) |no |BYE
|Q.850 ;cause=16 ;text="loc |user 9928019 |
