Version 7.2 849 Mediant 1000B Gateway & E-SBC
User's Manual 54. Reporting Information to External Party
CDR Field Range Description
the call session. For example, the device
generates leg ID "1" for the incoming leg
and leg ID "2" for the outgoing leg. If the
call is transferred, the device generates
leg ID "3" for the leg belonging
transfer target. Another example is a call
forking session where the leg ID
sequence may be as follows: incoming
leg is "1", outgoing leg to user's office
phone is "2" and outgoing leg to the
user's mobile phone is "3". If the call is
then transferred, the leg ID for the
transfer leg is "4".
Cid
Channel CID
MediaType
Media type (audio, video, or text)
Coder
Coder name
PacketInterval
10 to 200 ms Coder packet interval
LocalRtpIp
Local RTP IP address
LocalRtpPort
0 to 0xFFFF Local RTP port
RemoteRtpIp
Remote RTP IP address
RemoteRtpPort
0 to 0xFFFF Remote RTP port
InPackets
0 to 0xFFFFFFFF Number of packets received by the
device (local)
OutPackets
0 to 0xFFFFFFFF Number of packets sent by the device
(local)
LocalPackLoss
0 to 0xFFFFFFFF Number of packet loss of the entire
stream (local)
RemotePackLoss
0 to 0xFFFFFF (-1 if
information is unavailable)
Remote packet loss
RTPdelay
0 to 10000 ms (-1 if
information is unavailable)
Average RTP delay of the entire stream
RTPjitter
0 to 40000 samples (-1 if
unavailable)
RTP jitter
TxRTPssrc
0 to 0xFFFFFFFF Tx RTP SSRC
RxRTPssrc
0 to 0xFFFFFFFF Local RTP SSRC
LocalRFactor
0 to 120 (127 if information is
unavailable)
Local conversation quality
Note: If the RTCP XR feature is
unavailable (not licensed or disabled),
this R-factor VoIP metric is not provided.
Instead, the device sends the CDR field
with the value 127, meaning that
information is unavailable.
RemoteRFactor
0 to 120 (127 if information is
unavailable)
Remote conversation quality
Note: If the RTCP XR feature is
