Page #22 background imageLoading...
Page #22 background image
5 Signals
5.1 Signals via fieldbus
Feedback signals via Profibus DP can be configured. Configuration is possi
-
ble for both data structure and data contents.
Configuration is defined via the GSD file only. The selected configuration
can be indicated on the AUMATIC display.
Information It is possible to download the GSD file (General Station Description) from
the Internet: www.auma.com
Table of contents:
5.1.1 Configuration for process representation input: view
5.1.2 Configuration of adjustable (user-definable) signals: view
5.1.3 Configuration of fault signals: view
5.1.4 Percent/per mil coding for transmission values: view
5.1.1 Configuration for process representation input: view
The AUMATIC supports various data arrangements within the process rep-
resentation input.
The value of this parameter can be changed via the GSD file only.
Æ
Via the menu to parameter:
MAIN MENU (M0)
SETTINGS (M1)
PROFIBUS DP 1 (M1B)
BYTE ORDER PATTERN (M1B03)
Default value: 0
È
Description of the parameter settings:
0
Arrangement 1 is used.
1
Arrangement 2 is used.
2
Arrangement 3 is used.
3
Arrangement 4 is used.
Information Refer to “AUMATIC AC 01.1/ACExC 01.1 Profibus DP” manual (Device inte-
gration Fieldbus) for arrangement presentation and details on the Profibus
DP interface.
22
Actuator controls
AUMATIC AC 01.1/ACExC 01.1 Profibus DP Manual
VIEW
IN-PROC-IMAGE 1
0
C:ESC
