7.3 Limit switching setting
This setting is only possible for the non-intrusive version
For further information refer to page 8.
Æ
Via the menu to parameter:
MAIN MENU (M0)
SETTINGS (M1)
SET LIMIT SWITCHES (M10)
CLOSED POSITION (M100)
OPEN POSITION (M101)
Information For end position setting, turn selector switch to LOCAL position and move
the actuator into the end position, either via manual or motor operation
(using the push buttons). Then turn the selector switch back to position OFF
and accept end position.
Information
If an end position cannot be set:
Ò Chec
k the type of control unit in actuator.
47
Actuator controls
Manual AUMATIC AC 01.1/ACExC 01.1 Profibus DP
Valve damage due to direct approaching of mechanical end stop dur-
ing motor operation!
Ò During motor operation, interrupt travel before reaching the mechanical
v
alve/gearbox end stop (press push button STOP ).
SET LIMIT SWITC M100
CLOSED POSITION
63.3 %
¿:EDIT C:ESC
SET LIMIT SWITC M101
OPEN POSITION
63.3 %
¿:EDIT C:ESC
NOTICE
