5.2 Feedback via output contacts (binary) - (option)
These feedback signals are only available if a parallel interface is available
in addition to the fieldbus interface (refer to page 83).
The output contacts can be used to indicate operation modes of the actuator
or the controls as binary signals. The assignment of signals is freely
selectable. Example:
Output contact open = no
thermal fault
Output closes = thermal fault in actuator
The output contacts are described in the wiring diagram as follows:
.
Output contacts 1 to 5: DOUT1 through DOUT5
.
Alarm contacts: NC fault/NO ready
Table of contents:
5.2.1 Configuration for output contacts 1 to 5: view/edit
5.2.2 Configuration for alarm contacts (collective fault signal)
5.2.3 Output contacts 1 to 5: use as a running indication (blinker)
5.2.1 Configuration for output contacts 1 to 5: view/edit
Information Fault signals can be issued via the
ALARM CONTACT parameter, other sig-
nals via the output contacts 1 to 5.
Æ
Via the menu to parameter:
MAIN MENU (M0)
SETTINGS (M1)
I/O 1 (M14)
OUTPUT CONTACT 1 (M1412)
OUTPUT CONTACT 2 (M1413)
OUTPUT CONTACT 3 (M1414)
OUTPUT CONTACT 4 (M1415)
OUTPUT CONTACT 5 (M1416)
Default values: OUTPUT CONTACT 1 = END POSITION OPEN
OUTPUT CONTACT 2 = END POSITION CLOSED
OUTPUT CONTACT 3 = SELECTOR SWITCH REMOTE
OUTPUT CONTACT 4 = TSC FAULTS
OUTPUT CONTACT 5 = TSO FAULTS
Table 10 shows the signal descriptions for the LEDs and the output contacts:
27
Actuator controls
Manual AUMATIC AC 01.1/ACExC 01.1 Profibus DP
EDIT M1412
OUTPUT CONTACT 1
CLOSED POSITION
:EDIT ¿:OK C:ESC
Signal Description
NOT USED
No signals
CLOSED POSITION
Signals LSC (WSR) or LSC (WSR) and TSC
(DSR) (depending on type of seating)
OPEN POSITION
Signals LSO (WOEL) or LSO (WOEL) and
TSO (DOEL) (depending to type of seating)
RUNNING CLOSE
Actuator runs logically CLOSE
RUNNING OPEN
Actuator runs logically OPEN
ACTUATOR MOVING
Actuator is running from LOCAL, REMOTE, or
in manual operation (without position transmit
-
ter, only LOCAL or REMOTE operation are
indicated).
LSC (WSR)
Limit switch CLOSE operated
LSO (WOEL)
Limit switch OPEN operated
Table 10
