5.2.3 Output contacts 1 to 5: use as running indication (blinker)
Æ
Via the menu to parameter:
MAIN MENU (M0)
SETTINGS (M1)
I/O 1 (M14)
OUTPUT CONTACT 1 (M1412)
OUTPUT CONTACT 2 (M1413)
OUTPUT CONTACT 3 (M1414)
OUTPUT CONTACT 4 (M1415)
OUTPUT CONTACT 5 (M1416)
È
Description of the parameter settings:
CLOSING BLINK
Signal is active in end position CLOSED.
Signal is blinking for operation in direction CLOSE (depending on the
BLINKER parameter).
OPENING BLINK
Signal is active in end position OPEN.
Signal is blinking for operation in direction OPEN (depending on the
BLINKER parameter).
Information The output contacts/LEDs of the local controls (page 19) can also be used
to indicate whether the actuator is operated and if yes, in which direction.
Signal behaviour for BLINKER setting
Æ
Via the menu to parameter:
MAIN MENU (M0)
SETTINGS (M1)
LOCAL CONTROLS (M13)
BLINKER (M1311)
Default value: OFF IN MIDPOSITION
È
Description of the parameter settings:
OFF
Signal is active in end position.
Blinker (running indication) is switched off.
LIT IN MIDPOSITION
Signal is active in end position and blinking during operation in direction of
the end position.
The signal remains active in intermediate position.
Actuator controls
AUMATIC AC 01.1/ACExC 01.1 Profibus DP Manual
30
EDIT M1412
OUTPUT CONTACT 1
CLOSING BLINK
:EDIT ¿:OK C:ESC
EDIT M1311
BLINKER
OFF IN MIDPOSITION
:EDIT ¿:OK C:ESC
