6.5 Operation mode FAILURE
The operation mode FAILURE enables an initiation of failure operations in
case of signal loss or loss of bus communication.
If the FAILURE mode is enabled, the display indicates:
Table of contents:
6.5.1 Failure behaviour: switch on or off
6.5.2 Source for initiation (failure source): set for the failure operation.
6.5.3 Actuator reaction (failure position): set on loss of signal
6.5.4 Preset position definition
6.5.5 Failure delay time setting
6.5.6 Failure behaviour for bus communication loss
6.5.1 Failure behaviour: switch on or off
Æ
Via the menu to parameter:
MAIN MENU (M0)
SETTINGS (M1)
FAILURE BEHAVIOUR (M15)
FAILURE BEHAVIOUR (M1510)
Default value: OFF
Description of the parameter settings:
OFF
Failure behaviour is switched off.
GOOD SIGNAL FIRST
A failure operation is only initiated if no cable break is recognised after
switching on, but loss of signal is recognised later through cable break.
With this setting, it is ensured that the actuator does not perform a preset
failure action (failure position) when switched on without signal E1 con-
nected.
FAIL IMMEDIATE
A failure operation is initiated in case of cable break.
Information If
FAIL IMMEDIATE is switched on, a failure operation is initiated immedi-
ately after the actuator is switched on if a cable break has occurred.
41
Actuator controls
Manual AUMATIC AC 01.1/ACExC 01.1 Profibus DP
FAILURE MODE S0
EDIT M1510
FAILURE BEHAVIOUR
OFF
:EDIT ¿:OK C:ESC
