5.1.3 Configuration of fault signals: view
Fault signalling is made via byte 5.7.
Æ
Via the menu to parameter:
MAIN MENU (M0)
SETTINGS (M1)
PROFIBUS DP 1 (M1B)
BYTE 5.7 CONFIG. (M1B0B)
Default value: FAULT GROUP 3
È
Description of the parameter settings:
Table 9 indicates the values to be assigned for the alarm signals:
25
Actuator controls
Manual AUMATIC AC 01.1/ACExC 01.1 Profibus DP
VIEW
BYTE 5.7 CONFIG.
FAULT GROUP 3
C:ESC
Value Signals (collective fault signal)
FAULT GROUP 1
–
FAULT IND.
–
NOT READY IND.
FAULT GROUP 2
–
FAULT IND. without torque fault
–
NOT READY IND.
FAULT GROUP 3
–
FAULT IND.
FAULT GROUP 4
–
FAULT IND. without torque fault
FAULT GROUP 5
–
FAULT IND.
–
NOT READY IND.
–
WARNING IND.
FAULT GROUP 6
–
FAULT IND. without thermal fault
–
NOT READY IND.
FAULT GROUP 7
–
FAULT IND. without both torque and thermal
faults
–
NOT READY IND.
FAULT GROUP 8
–
FAULT IND. without thermal fault
FAULT GROUP 9
–
FAULT IND. without both torque and thermal
faults
FAULT GROUP 10
–
FAULT without thermal fault
–
NOT READY IND.
–
WARNING IND.
Table 9
Signals/
indications on the display
Description
EMCY STOP BUTTON
The EMERGENCY - STOP button (option) has
been operated
FIBER OPTIC LOSS
Fault at the fibre optic module (option)
BRAKE SUPPLY FAIL
Not available
NOTIFY RESET
Not available
DIG.IN 1 BUS2
Not available
DIG.IN 2 BUS2
DIG.IN 3 BUS2
DIG.IN 4 BUS2
RUNNING OPEN (LOCAL)
Actuator is running in direction OPEN (by an
operation command from the local controls or
by turning the handwheel)
RUNNING CLOSE (LOCAL)
Actuator is running in direction CLOSE (by an
operation command from the local controls or
by turning the handwheel)
INTERMED. POSITION
Actuator in intermediate position
