Actuator controls
AUMATIC AC 01.1/ACExC 01.1 Profibus DP Manual
Signals/
indications on the display
Description
OFF SW. POSITION
Selector switch in position OFF
REMOTE MODE
Operation mode REMOTE active
SETPOINT MODE
Operation mode SETPOINT MODE
INTERMED. POS. 1
Signalling of the intermediate positions 1 to 4.
Signal behaviour according to
POS.1
CONTROL
to POS.4 CONTROL parameters
INTERMED. POS. 2
INTERMED. POS. 3
INTERMED. POS. 4
STEPPING MODE
Programmed stepping range (START STEP
STOP STEP
parameters) has been entered
CLOSING BLINK
Signal is blinking for operation in direction
CLOSE. Signal is active in end position
CLOSED.
OPENING BLINK
Signal is blinking for operation in direction
OPEN. Signal is active in end position OPEN.
FAULT IND.
Collective signal includes: internal fault, torque
fault, phase loss, thermal fault, and
configuration fault (refer to status indications on
page 92)
WARNING IND.
Collective signal includes: operation time
warning, warning starts/run, no reference
operation, internal warnings, and signal losses
(refer to status indications on page 92)
NOT READY IND.
Collective signal includes: remote ready,
selector switch not REMOTE, incorrect
operation command, emergency (refer to status
indications on page 93)
SETPOINT REACHED
Actuator is in nominal position
LOSS OF PHASE
One phase is missing
I/O ANALOG IN2 LOSS
Signal loss of the parallel interface analogue
input 2
I/O ANALOG IN1 LOSS
Signal loss of the parallel interface analogue
input 1
SELECTOR NOT REMOTE
Selector switch not in position REMOTE
WRONG COMMAND
Wrong command received (several operation
command bits set or setpoint > 100 % or >
1000 ‰)
INTERNAL FAULT
An internal fault has occurred, see diagnostic
indication D2
PE FAULT
Not available
INTERNAL FEEDBACK
Actuator has not yet been opened to full end
position OPEN or closed to full end position
CLOSED
INTERNAL WARNING
An internal warning has occurred, see
diagnostic indication D3
CHANNEL 2 ACTIVE
Communication is made via the redundant
channel
RUNNING LOCAL
The actuator is operated by an operation
command from the local controls
RUNNING REMOTE
The actuator is operated by an operation
command from REMOTE
RUNNING WITH HANDWHL
The actuator is operated by turning the
handwheel
PROPOTIONAL RUNNING
Not available
PHYS.DRIVE BREAK
Actuator is in pause time of stepping mode
CLEAR STATE
The Profibus DP interface has received a
Global Control CLEAR telegram
DIG.IN 1 BUS1
A +24 DC signal is present at the digital input
(1 to 4) of the Profibus interface
DIG.IN 2 BUS1
DIG.IN 3 BUS1
DIG.IN 4 BUS1
INTERMED. POS. 5
Signalling of the intermediate positions 5 to 8.
Signal behaviour according to
POS.5
CONTROL
to POS.8 CONTROL parameters
INTERMED. POS. 6
INTERMED. POS. 7
INTERMED. POS. 8
