7.7.12 Input range of process setpoint E1: view
Refer to subclause Positioner “ Input range of setpoint value E1: view/edit”
(page 60).
7.7.13 Input range of process variable E4: view/edit
In Profibus DP standard version, the process variable E4 is transmitted via
an additional analogue 0/4 – 20 mA input (wiring diagram designation =
ANIN2).
The input range is determined by an initial and an end value.
Æ
Via the menu to parameter:
MAIN MENU (M0)
CONFIGURATION (M4)
SETUP (M41)
DP1 ANLOG IN2 START (M411N)
DP1 ANLOG IN2 END (M411P)
Default values: DP1 ANLOG IN2 START = 0 mA
DP1 ANLOG IN2 END
= 20 mA
Setting ranges: DP1 ANLOG IN2 START = 0 mA to 20 mA
DP1 ANLOG IN2 END
= 0 mA to 20 mA
Information
.
If the measuring values are 0.3 mA below the initial value, a wire break
is indicated as a warning.
69
Actuator controls
Manual AUMATIC AC 01.1/ACExC 01.1 Profibus DP
VIEW
DP1 ANLOG IN2 END
20.0 mA
C:ESC
VIEW
DP1 ANLOG IN2 START
0.0 mA
C:ESC
