5.1.4 Percent/per mil coding for transmission values: view
The coding of Profibus DP transmission values can be configured.
Æ
Via the menu to parameter:
MAIN MENU (M0)
SETTINGS (M1)
ANALOGUE VALUES DP (M1B0C)
Default value: 0– 100 PER CENT
Default value: 0-1000 PER MIL
È
Description of the parameter settings:
0-100 PER CENT
Encoding of all analogue measured values is indicated in per cent.
0-1000 PER MIL
Encoding of all analogue measured values is indicated in per mil.
26
Actuator controls
AUMATIC AC 01.1/ACExC 01.1 Profibus DP Manual
EDIT
ANALOGUE VALUES DP
0-1000 PER MIL
C:ESC
