7.16.4 Operating time monitoring
This function allows the monitoring of the operating time of the actuator. If
the actuator needs longer than the set time (
MAX. RUN TIME parameter)
to move from end position OPEN to end position CLOSED, the following
warning signals are given (the actuator is not stopped):
.
Status indication S0: operation mode OFF/LOCAL = WRN+NR
.
Status indication S0/S6: operation mode REMOTE = WARNING
.
Status indication S2: WARNING OPER. TIME
The warning signals are automatically cleared when a new operation com-
mand is executed.
When the actuator moves from an intermediate position to an end position,
the set monitoring time for the whole stroke is assigned in relation to the
remaining stroke/travel.
Switching the operating time monitoring on/off
Information This parameter is also used to switch the monitoring of the max. number of
starts per hour and the max. running time per hour (page 84) on/off.
Æ
Via the menu to parameter:
MAIN MENU (M0)
CONFIGURATION (M4)
SPECIAL FUNCTIONS (M40)
MONITOR TRIGGERS (M4016)
Default value: FUNCTION ACTIVE
È
Description of the parameter settings:
FUNCTION NOT ACTIVE
The operating time monitoring is switched off
FUNCTION ACTIVE
The operating time monitoring is switched on
Setting the max. permissible operating time
Æ
Via the menu to parameter:
MAIN MENU (M0)
SETTINGS (M1)
MONITOR TRIGGERS (M18)
MAX. RUN TIME (M1812)
Default value: 900 s
Setting range:
4 to 36,000 seconds (4 seconds to 10 hours)
88
Actuator controls
AUMATIC AC 01.1/ACExC 01.1 Profibus DP Manual
EDIT M4016
MONITOR TRIGGERS
FUNCTION ACTIVE


:EDIT ¿:OK C:ESC
EDIT M1812
MAX. RUN TIME
900 s


:EDIT ¿:OK C:ESC
