8 Corrective action
8.1 Fault indications and warning indications
Faults interrupt or prevent electrical actuator operation.
Warnings have no influence on the electrical actuator operation. They only
serve information purposes.
Fault and warning indications are shown on the display.
Table of contents:
8.1.1 Status indication S0 – Faults and warnings
8.1.2 Status indication S1 – Faults
8.1.3 Status indication S2 – Warnings
For further status indications in the display, refer to page 15 et seqq.
8.1.1 Status indication S0 – faults and warnings
Line 4 of status indication
S0 shows faults and warnings.
È
Description of the fault indications:
FAULT IND.
A fault has occurred
Ò F
or further information, press qp and go to status indication S1.
WARNING IND.
A warning has occurred
Ò F
or further information, press
qp and go to status indication S2 .
FAULT + WARNING
Faults as well as warnings have occurred.
Ò F
or further information, press
qp and go to status indication S1
(faults) or S2 (warnings).
NOT READY IND.
The actuator cannot be operated from REMOTE. The actuator can only be
operated via the local controls.
Ò F
or further information, press
qp and go to status indication S3
(cause of fault signals).
FLT+NR
Faults and the NOT READY IND. signal have occurred.
Ò F
or further information, press
qp and go to status indications S1 or
S3.
WRN+NR
Faults and the NOT READY IND. signal have occurred.
Ò F
or further information, press
qp and go to status indications S2 or
S3 .
FLT+WRN+NR
Faults, warnings, and the NOT READY IND. signal have occurred.
Ò
F
or further information, press
qp and go to status indication S1 to
S3.
91
Actuator controls
Manual AUMATIC AC 01.1/ACExC 01.1 Profibus DP


LOCAL MODE S0
OPEN
E2 100%
FAULT IND.
