7.4 Intermediate positions (option)
The AUMATIC allows to define up to 8 intermediate positions.
Condition The actuator is either equipped with:
.
an MWG (for Non-Intrusive version), or
.
a potentiometer (5 kW) or
.
an RWG
In these versions, the positioning of the intermediate positions is made via
softw
are parameters.
Selection of the intermediate positions can be made either via push buttons
from LOCAL or via the fieldbus interface from REMOTE with the standard
commands OPEN and CLOSE. The actuator stops when reaching the inter-
mediate position. The operation command has to be cleared via the com-
mand STOP and issued again to resume operation to the next intermediate
position.
Information If the intermediate positions are to be approached directly (without stop), the
multiport valve function (page 52) is available as an option.
Table of contents:
7.4.1 Display indication: enable view
7.4.2 Intermediate positions: switch on or off
7.4.3 Intermediate position definition
7.4.4 Operation behaviour = actuator behaviour definition
7.4.5 Intermediate positions: set the signalling
7.4.1 Display indication: enable view
The
INTERMED. POSITION parameter must be set to VIEW ENABLED to
carry out settings in the intermediate positions.
Æ
Via the menu to parameter:
MAIN MENU (M0)
CONFIGURATION (M4)
SPECIAL FUNCTIONS (M40)
INTERMED. POSITION (M4015)
Default value: VIEW NOT ENABLED
Description of the parameter settings:
VIEW NOT ENABLED
The parameter for the intermediate positions are not indicated in the display.
VIEW ENABLED
The parameter for the intermediate positions are indicated in the display.
48
Actuator controls
AUMATIC AC 01.1/ACExC 01.1 Profibus DP Manual
EDIT M4015
INTERMED. POSITION
VIEW NOT ENABLED


:EDIT ¿:OK C:ESC
