7.6.8 Input range of setpoint 1: view/edit
The parameters of this setting depend on the pre-set setpoint source
(
SETPOINT E1 (M4100) parameter, page 59).
Initial and end value via the Profibus DP interface
In Profibus DP standard version, the setpoint E1 is transmitted via the pro
-
cess representation.
The input range is 0 – 100 percent or 0 – 1,000 per mil. The change-over
between percent and per mil is made via the “Format of analogue Indica-
tions” parameter in the GSD file.
Initial and end value via I/O interface
Optionally, setpoint E1 can be transmitted via an analogue input instead of
the fieldbus (channel 1 or channel 2). This is possible for the following ver-
sions:
a) in addition to the Profibus DP interface, the AUMATIC is equipped with a
further parallel interface (refer to page 83)
b) the AUMATIC is equipped with additional control inputs (refer to page 80)
The input range amounts to 0/4 – 20 mA. It is possible to modify the input
range via the display for both versions:
Version a) for setpoint source from parallel interface, analogue input 1:
Æ
Via the menu to parameter:
MAIN MENU (M0)
CONFIGURATION (M4)
SETUP (M41)
I/O1 ANLOG IN1 START (M410H)
I/O1 ANLOG IN1 END (M410I)
Default values: I/O1 ANLOG IN1 START = 0 mA
I/O1 ANLOG IN1 END = 20
mA
Setting ranges: I/O1 ANLOG IN1 START = 0 to 20 mA
I/O1 ANLOG IN1 END = 0
to 20 mA
Version b) for setpoint source Profibus DP, analogue input 1
Æ
Via the menu to parameter:
MAIN MENU (M0)
CONFIGURATION (M4)
SETUP (M41)
DP1 ANLOG IN1 START (M410L)
DP1 ANLOG IN1 END (M410M)
Default values: DP1 ANLOG IN2 END = 0 mA
DP1 ANLOG IN1 END = 20
mA
Setting ranges: DP1 ANLOG IN1 START = 0 to 20 mA
DP1 ANLOG IN1 END = 0
to 20 mA
Information If the measuring values are 0.3 mA below the initial value a wire break is
indicated as a warning.
60
Actuator controls
AUMATIC AC 01.1/ACExC 01.1 Profibus DP Manual
VIEW
I/O1 ANLOG IN1 END
20 mA
C:ESC
VIEW
I/O1 ANLOG IN1 START
0.0 mA
C:ESC
VIEW
DP1 ANLOG IN1 END
20.0 mA
C:ESC
VIEW
DP1 ANLOG IN1 START
0.0 mA
C:ESC
