OFF IN MIDPOSITION
Signal is active in end position and blinking during operation in direction of
the end position.
The signal is off in intermediate position.
Information The
BLINKER parameter also influences the blinking behaviour of the indi
-
cation lights/LEDs on the local controls.
5.3 Feedback signals (analogue) - (option)
These feedback signals are only available if a parallel interface is available
in addition to the fieldbus interface (refer to page 83).
Depending on the actuator equipment, different signals can be recorded and
issued as continuous values, e.g. 4 to 20 mA.
Table of contents:
5.3.1 Position transmitter/actual position source (E2): view
5.3.2 Source of the torque signal E6: view
5.3.3 Feedback signals via analogue output 1: view
5.3.4 Signal range at the analogue output 1: view/edit
5.3.5 Feedback signals via analogue output 2: view
5.3.6 Signal range at the analogue output 2: view/edit
5.3.1 Position transmitter/actual position source (E2): view
The valve position can be transmitted as a continuous signal by various
position transmitters: The type of position transmitter/actual position source
(E2) installed in the actuator is indicated here.
This value is set in the factory and can only be changed by the AUMA ser-
vice.
Æ
Via the menu to parameter:
MAIN MENU (M0)
CONFIGURATION (M4)
SETUP (M41)
FEEDBACK E2 (M4101)
Default value: POTENTIOMETER (for Non-Intrusive: MWG)
The following actual position sources (E2) are available:
È
Description of the parameter settings:
NONE
There is no position transmitter available in the actuator.
POT.
There is a potentiometer installed in the actuator.
0–20mA
There is an RWG installed in the actuator. The position feedback signal
amounts to 0 – 20 mA.
4–20mA
There is an RWG installed in the actuator. The position feedback signal
amounts to 4 – 20 mA.
31
Actuator controls
Manual AUMATIC AC 01.1/ACExC 01.1 Profibus DP
VIEW
FEEDBACK E2
POT.
C:ESC
