5.1.2 Configuration of adjustable (user-definable) signals: view
Within the process representation input, the users can configure the data
contents of 4 signal bytes out of a predefined signal set themselves.
Configuration is defined via the GSD file only.
Æ
Via the menu to parameter:
MAIN MENU (M0)
SETTINGS (M1)
PROFIBUS DP 1 (M1B)
BYTE 5.0 CONFIG. (M1B04)
to(M1B0A)
BYTE 6.0 CONFIG. (M1B0D)
to(M1B0K)
BYTE 7.0 CONFIG. (M1B0L)
to(M1B0S)
BYTE 8.0 CONFIG. (M1B0T)
to(M1B0a)
Example Byte 5.0:
Default values: Refer to “AUMATIC AC 01.1/ACExC 01.1 Profibus DP”
manual (Fieldbus device integration), process representa-
tion input.
È
Description of the parameter settings:
23
Actuator controls
Manual AUMATIC AC 01.1/ACExC 01.1 Profibus DP
Signals/
indications on the display
Description
NOT USED
No signals
CLOSED POSITION
Signals LSC (WSR) or LSC (WSR) and TSO
(DOEL) (depending on type of seating)
OPEN POSITION
Signals LSO (WOEL) or LSO (WOEL) and
TSO (DOEL) (depending to type of seating)
RUNNING CLOSE
Actuator runs logically CLOSE
RUNNING OPEN
Actuator runs logically OPEN
ACTUATOR MOVING
Actuator is running from LOCAL, REMOTE, or
in manual operation. (Without position
transmitter only the LOCAL or REMOTE
operation is indicated.)
LSC (WSR)
Limit switch CLOSE operated
LSO (WOEL)
Limit switch OPEN operated
TSC (DSR)
Torque switch CLOSE operated
TSO (DOEL)
Torque switch OPEN operated
THERMO FAULT
Motor protection has tripped (reset may be
necessary)
TORQUE FAULT (CLOSE)
Torque fault in direction CLOSE occurred
TORQUE FAULT (OPEN)
Torque fault in direction OPEN occurred
TORQUE FAULT (GEN.)
Torque fault CLOSE or OPEN (combined
signal)
SETPOINT E1 LOSS
Nominal value signal is by 0.3 mA lower than
the lowest set value
FEEDBACK E2 LOSS
Actual position signal is by 0.3 mA lower than
the lowest set value
SPEED E3 LOSS
Not available
TORQUE E6 LOSS
Torque signal is by 0.3 mA lower than the
lowest set value
WARNING OPER.TIME
The programmed max. operating time for an
OPEN - CLOSE operation has been exceeded
WARNING STARTS/RUN
The max. number of starts/h or max. running
time/h has been exceeded.
LOCAL SW. POSITION
Selector switch in position LOCAL
REMOTE SW. POSITION
Selector switch in position REMOTE
Table 8
VIEW
BYTE 5.0 CONFIG.
CLOSED POSITION
C:ESC
