MWG
There is an MWG (magnetic limit and torque transmitter) installed in the
actuator.
5.3.2 Source of the torque signal E6: view
This value is set in the factory and can only be changed by the AUMA ser
-
vice.
Æ
Via the menu to parameter:
MAIN MENU (M0)
CONFIGURATION (M4)
SETUP (M41)
TORQUE E6 (M4103)
Default value: depending on actuator
È
Description of the parameter settings:
NONE
There is no electronic torque monitoring available.
LOGIC ANALOG IN1
The torque signal is transmitted from an external sensor via the logic board
to the analogue input 1.
MWG
The torque signal is generated using the MWG installed in the actuator.
5.3.3 Feedback signals (configuration) via analogue output 1: view
Configuration of analogue output 1 (of the I/O).
Designation in the wiring diagram: ANOUT1.
This value is set in the factory and can only be changed by the AUMA ser-
vice.
Æ
Via the menu to parameter:
MAIN MENU (M0)
CONFIGURATION (M4)
SETUP (M41)
I/O1 ANALOG OUT1 (M410A)
Default value: POSITION E2
È
Description of the parameter settings:
NOT USED
Analogue output 1 not used.
FEEDBACK E2:
Position feedback (analogue output 1 assigned to actual position signal).
32
Actuator controls
AUMATIC AC 01.1/ACExC 01.1 Profibus DP Manual
VIEW
I/O1 ANALOG OUT1
POSITION E2
C:ESC
VIEW
TORQUE E6
MWG
C:ESC
