7.5.2 Check: Positioner active?
The positioner must be available. This value is set in the factory.
Æ
Via the menu to parameter:
MAIN MENU (M0)
CONFIGURATION (M4)
SPECIAL FUNCTIONS (M40)
POSITIONER (M4000)
The POSITIONER parameter must be set to POSITIONER ENABLED.
È
Description of the parameter settings:
FUNCTION NOT ACTIVE
There is no positioner available.
POSITIONER ENABLED
The controls are equipped with a positioner.
7.5.3 Display indication: enable view
The indication of the multiport valve intermediate positions in the display is
performed as described on page 17.
7.5.4 Intermediate positions: switch on or off
The multiport valve intermediate positions are switched on/off as described
on page 48.
7.5.5 Intermediate position setting
Each of the 8 intermediate positions must be programmed. For direct selec-
tion of the intermediate positions from either LOCAL or REMOTE, it is suffi-
cient to define the position (
POS.1-8) parameter of each intermediate
position.
Æ
Via the menu to parameter:
MAIN MENU
SETTINGS (M1)
INTERMED. POSITION (M1C)
POS.1 (M1C10)
Setting ranges: 0.0 % to 100.0 % of the travel (from OPEN to CLOSED)
Typically all 8 outputs of the valve are distributed evenly over 360°, therefore the
limit switch CLOSE should be set to output 1 and the limit switch OPEN to output
8. Afterwards the positions of the intermediate positions can be set:
Intermediate position 1: POS.1 0.0 % (output 1)
Intermediate position 2: POS.2 14.3 % (output 2)
Intermediate position 3: POS.3 28.6 % (output 3)
Intermediate position 4: POS.4 42.9 % (output 4)
Intermediate position 5: POS.5 57.1 % (output 5)
Intermediate position 6: POS.6 71.4 % (output 6)
Intermediate position 7: POS.7 85.7 % (output 7)
Intermediate position 8: POS.8 100.0 % (output 8)
53
Actuator controls
Manual AUMATIC AC 01.1/ACExC 01.1 Profibus DP
EDIT M1C10
POS.1
0.0 %
:EDIT ¿:OK C:ESC
VIEW
POSITIONER
POSITIONER ENABLED
C:ESC
