AUMA Aumatic AC 01.1 User Manual

8.1.2 Status indication S1 - faults
Faults are indicated within this group:
È
Description of the fault indications:
NO FAULT
No fault has occurred.
INTERNAL FAULT
Internal fault has occurred.
For further information:
1. Go to group
D0: Press C and hold down until the diagnostic indication
D0 is displayed.
2. Go to diagnostic indication
D2 : Press q twice.
TORQUE FAULT (CLOSE
Torque fault in direction CLOSE.
Ò Oper
ation command in direction OPEN, or
Ò Press Reset push button.
TORQUE FAULT (OPEN)
Torque fault in direction OPEN
Ò Oper
ation command in direction CLOSE, or
Ò Press Reset push button.
LOSS OF PHASE
One phase is missing.
Ò T
est/connect phases.
THERMAL FAULT
Motor protection tripped.
Ò Cool off
, wait.
Ò If the fault indication display persists after cooling off:
–
Set selector switch to position Local control (LOCAL).
–
Reset fault indication via Reset push button.
Ò Check fuse F4.
CONFIGURATION FAULT
The controls’ configuration is incorrect.
For further information:
Ò Cool off
, wait.
1. Go to group
D0: Press C and hold down until the D0 diagnostic indica-
tion is displayed.
2. Go to diagnostic indication
D4: Press q four times.
8.1.3 Status indication S2 – warnings
Warnings are indicated within this group:
È
Description of the warnings:
NO WARNING
No warnings have occurred.
WARNING RUN.TIME
The preset running time for a travel between end position OPEN and end
position CLOSED has been exceeded.
92
Actuator controls
AUMATIC AC 01.1/ACExC 01.1 Profibus DP Manual


FAULT IND. S1
NO FAULT


WARNING IND. S2
NO WARNING
