Installation
Instruction handbook b maXX BM3000, BM3200, BM3300
Document no. 5.11018.11
135
of 218
7
1-phase device with internal ballast resistor BM3XXX-XEXX-XXXXX-B-XXXXX-
Figure 55: Connections at the top, BM3XXX-XE with internal ballast resistor
X300:
Signal bus
X202:
Power supply connection
X205:
Connection
DC-link
X200:
24V-voltage supply
