Pivotable Triple Spool Holder
1
⦁
remove spool-pin cover vertically upwards
⦁
pull up the telescopic rod and ensure that all the parts snap into place
⦁
swing spool pin to the right until it is engaged
►
this ensures a good overall view and access to the spool pins
►
eyelet 1 is used when winding a bobbin
1
Presser foot lifter
Raising or lowering presser foot via FHS.
Attaching the Free Hand System
⦁
insert into the opening 1
Raising and lowering the presser foot
⦁
with your knee, push lever to the right
⦁
you should be able to operate the FHS with your knee in your normal sitting
position
►
the presser foot is raised; the feed dog is lowered simultaneously. The
thread tension is released
►
the feed dog is raised as soon as the first stitch is sewn
Your dealer can adjust the FHS if necessary.
