Stitch width and Stitch length Knobs
(Multifunction)
to adjust stitch width or stitch length
to alter thread tension
to set the buttonhole slit width or the button
size
to adjust the balance
various alterations in the Setup-Program
various alterations when embroidering
«Needle position»-buttons
⦁
press the left button
►
needle moves to the left
⦁
press the right button
►
needle moves to the right
⦁
keep button pressed
►
quick change
total of 11 needle positions (5 left, 5 right,
1 center = 0)
Needle stop position up and «Quick reverse»-
button
If «Quick reverse»-button is pressed while sewing
or after stopping (e.g. zig-zag) with programmed
needle stop up, the sewing computer sews one
stitch forward before it switches to sewing in
reverse.
Needle stop position down and «Quick
reverse»-button
If «Quick reverse»-button is pressed after stopping
(e.g. zig-zag) with programmed needle stop
down, the sewing computer switches to sewing in
reverse immediately.
«Presser foot position»-button
⦁
press the button
►
the presser foot is lowered and raised a bit
again for easy positioning of the material
►
the presser foot is lowered on the fabric when
start sewing
⦁
press the button again
►
the foot is raised and the feed dog is lowered
simultaneously
«Automatic thread cutter»-button
the upper and the lower threads are cut
automatically
2-6 securing stitches can be programmed in
the Setup-Program. These are sewn before
the thread is cut
«Needle stop»-button
⦁
press the button
►
the needle is raised or lowered in the same
way as by sinking the heel back on the foot
control
«Automatic Securing Program»-button
⦁
press the button before sewing start = the
individual pattern/combination is secured at
the beginning with the number of programmed
stitches
⦁
keep the button pressed while sewing = the
sewing computer stops at once and sews the
number of programmed stitches
⦁
the number and type of the securing stitches
can be programmed in the Setup-Program
