Stitch plate
Marks on the stitch plate
the stitch plate is marked with vertical, horizontal and diagonal lines in mm
and inches
the lines help to guide the fabric for sewing seams and precise topstitching,
etc.
the horizontal markings are helpful for sewing corners and buttonholes, etc.
the diagonal markings are useful for quilting
needle insertion point is position «0» (center needle position)
the vertical measurements correspond to the distance between the needle
and the line
measurements are marked to the right and to the left of center needle
position
1
2
1
Removing the Stitch Plate
⦁
raise the presser foot and needle
⦁
turn power switch to «0» (off)
⦁
press the stitch plate down at the right back corner 1 until it flips up
►
remove stitch plate
Replacing the Stitch Plate
⦁
place the stitch plate over the opening 2 and press down until it clicks into
place
9 mm
5.5 mm (optional accessory)
Exchanging the Stitch Plate
Whenever the stitch plate is exchanged, it is imperative to adjust the
settings in Security Program accordingly, see page 32.
Changing the presser foot
Removing the presser foot
⦁
raise the needle and presser foot
⦁
turn power switch to «0» (off)
⦁
raise the clamping lever 1
⦁
remove the presser foot
Attaching the presser foot
⦁
guide the presser foot upwards over the cone
⦁
press the clamping lever 1 down
3
3
1
2
