Preparation
⦁
turn power switch on (to «I»)
⦁
place empty bobbin on Pin 1, white mark in front
►
the bobbin winding screen appears
►
the amount of bobbin fill is recognized by the system and displayed by a
bar above the selectable bobbin fill
⦁
place thread spool on the front spool pin 2 and thread the respective guides
3 on the telescope
Winding the Bobbin
⦁
hold thread with both hands, guide the thread in the thread guide on the
swivel plate 4 in the direction of the arrows and around the bobbin pre-
tension 5
⦁
wind the thread one to two times around the empty bobbin 6 following the
direction of the arrows and pull any excess thread in the direction of the
arrows, cut off on the thread cutter 7
⦁
select the bobbin filling, standard = 100%
⦁
touch the green «Start»-icon 8
⦁
adjust the winding speed via the «+»- or «-»-icon or the stitch width or stitch
length knob
►
winding process stops as soon as the selected fill percentage is reached
⦁
remove the bobbin and pull the thread over the thread cutter
►
the screen is closed
Winding the Bobbin
Interrupting the winding process
⦁
the winding process can be interrupted while winding by touching the
«Start»-icon 8 and the Display can be closed by touching the «Close»-icon
top right
It is possible to wind the bobbin while embroidering.
We recommend, however, to reduce the winding speed.
1
3
7
5
6
2
4
Continuing the winding process
⦁
touch the «bobbin»-icon 9
►
the winding Display opens
⦁
touch «Start» to start winding process
►
the winding process is continued
9
⦁
touch the «i»-icon in the bobbin winder Display
►
an animation how to wind the lower thread appears
Manual mode
⦁
touch the «man»-icon
►
the winder will run as long as the «Start»-icon is pressed
8
