ATTENTION!
It is absolutely essential to use the correct foam disc under the
thread spool.
Radial Thread Guide
Various Options of Application
Vertical thread unwinding (with or without lubricator) from normal spool pin
or optional multiple spool holder (Fig. 5-7)
Radial thread unwinding (with or without lubricator) (Fig. 8)
during the initial threading of the sewing computer and when the radial
thread release is used it is advisable to pull an extra inch of thread from the
spool before the threader button is pushed (Fig. 9)
How to use the thread guide:
it is preferable to replace the standard foam disc with the foam rotary disc (with
white plastic inner part) on the rear spool pin.
Application
The extra thread guide ensures the consistent thread release, when using
threads i.e. metallic, lively or evenly wound thread spools.
place thread spool on spool pin and guide thread through thread guide.
Then run thread via middle eyelet of telescopic rod. Continue threading the
sewing computer as normal
during the initial threading of the sewing computer and when the radial
thread release is used it is advisable to pull an extra inch of thread from the
spool before the threader button is pushed
Any of the two spool pins (see arrow markings) can be used. However, it is
best to use the rear pin due to its more favorable unwinding angle. Refrain
from using the pin of the winder.
In order to achieve perfect stitching results, it might be necessary to reduce the
upper-thread tension slightly when using the radial thread unwinding and
depending on the thread used.
5
6
7
8
