8 Error Handling Volume 3
Code
Error message
Error Handling N=Normal S=Sensitive Error Log HART
®
Digital Out Fault current SHUTDOWN Slave Status Master Status Self-repairing
328 Temperature
warning
N xxx ggx
S xxxx bbx
329 Temperature out
of allowed limits
N xxxx bbx
S xxxxxbb–
330 Detector mal-
function
N xxxx bbx
S xxxx bbx
400 Data flow N x x x x x b b –
S xxxxxbb–
401 Supply 11V N x x x x b b x
S xxxx bbx
402 Supply 5V N x x x x b b x
S xxxx bbx
403Supply 5VM N xxxx bbx
S xxxx bbx
404 Supply 3.3V N x x x x x b b –
S xxxxxbb–
405 RS-485 Commu-
nication error
N xxxx bbx
S xxxx bbx
406 Remote device
warning
N xxx uux
S xxx uux
407 Remote device
error
N xxxx bbx
S xxxx bbx
500 Data flow N x x x x x b b –
S xxxxxbb–
502 Digital input mal-
function
Nxxx gux
S xxxx gbx
503 Digital output
malfunction
N xxxx ggx
S xxxx ggx
504 Inherited Mes-
sage
N x ggx
S x ggx
600 Data flow N x x x x x b b –
S xxxxxbb–
601License Key Error N xxxxxbb–
S xxxxxbb–
603 Measuring Error
check <Error
Status>
Nxxx gu–
S xxxx gb–
604 Decay Compen-
sation Error
N xxx gu–
S xxxx gb–
605 Source Exchange N x x x g g x
S xxx gux
606 Radiation Inter-
ference
N xxx gf x
S xxxx gf x
607 RID Interference N x x x g g x
S xxx ggx
608 Inherited Mes-
sage
Nx ggx
Sx ggx
609 Rate Factor
exceeds its limit
N xxx gux
S xxx gux
610 Inherited Mes-
sage
Nx ggx
Sx ggx
611 Inherited Mes-
sage
Nx ggx
Sx ggx
612 Inherited Mes-
sage
Nx ggx
Sx ggx
613 Inherited Mes-
sage
Nx ggx
Sx ggx
700Data flow N xxxxxbbx
S xxxxxbb–
701 Impulse differ-
ence
N xxxx ggx
S xxxx ggx
702 Current loop mal-
function
N xxxx gg–
S xxxx gg–
703 CLoop Monitor-
ing Disabled
Nx ggx
Sx ggx
704 ERROR GND CPU
ST6
N xxx ggx
S xxxx ggx
900Data Flow N xxxxxbb–
S xxxxxbb–
901 Signal Unlocked N x x x g u x
S xxxx gbx
Code
Error message
Error Handling N=Normal S=Sensitive Error Log HART
®
Digital Out Fault current SHUTDOWN Slave Status Master Status Self-repairing
