SENSseries LB 480 Level measurement
BERTHOLD TECHNOLOGIES GmbH & Co. KG
3 – 433
Volume 3 8 Error Handling
3
8.2.2 Error Handling
Code
Error message Error reason Error Handling
101 HW module missing or not tested
Hardware error
The error can be eliminated only by
replacing the detector or the detector
electronics.
103 RAM Error
104 Device Error
108 Safety parameter invalid
200 Data flow
201 Error by analog input calibration
202 Clock signal deviation
300 Data flow
301 Error by ADC calibration
302 Error by DAC calibration
303 Supply 5.0V
304 Reference 2.0V
305 Reference 2.5V
306 ERROR GND CPU ST9
307 No impulses in measuring channel
308 No impulses in control channel
309 No impulses in auxiliary channel
310 Impulse difference measuring channel
311 Impulse difference control channel
312 Impulse difference auxiliary channel
313 Instable pulse rate
314 Threshold of measurement channel 1
315 Threshold of measurement channel 2
316 Threshold of control channel 1
317 Threshold of control channel 2
318 Threshold of auxiliary channel 1
319 Threshold of auxiliary channel 2
330 Detector malfunction
400 Data flow
401 Supply 11V
402 Supply 5V
403 Supply 5VM
404 Supply 3.3V
500 Data flow
502 Digital input malfunction
503 Digital output malfunction
600 Data flow
700 Data flow
701 Impulse difference
704 ERROR GND CPU ST6
900 Data Flow
