BERTHOLD TECHNOLOGIES LB 480 - Page 78

54733BA26
1 – 78 02.2017
5 Explosion Protection Volume 1
Certificate:
70009819
Project:
70066628
Master Contract:
215040
Date Issued:
2016-
03-07
DQD 507 Rev. 2012-05-22 Page 5
IIB
IIC
L
o
(mH)
C
o
(µF)
L
o
(mH)
C
o
(µF)
17.0
0.820
4.0
0.107
Or
Hart-current output (Sink Mode) (Terminal 17, 18)
Type of protection Intrinsic Safety Ex ia IIC Maximum Values:
U
i
= 30.0 V; I
i
= 152.0 mA; P
i
= 1.14 W; C
i
= 3.0 nF; L
i
= 20.0 µH
Note: the HART current output (source mode or sink mode) of the current output module are safely electrically
isolated from earth and all other circuits.
Schedule of Limitations:
1) The interface circuit RS485 serves exclusively for intercommunication of the probes and must not be
connected to an external RS485 circuit.
2) In gas atmospheres for the choice of Group IIB or IIC for the intrinsically safe circuits, all intrinsically
safe circuits and the scintillation meter LB 480 series shall be fully operated in the selected Group IIB or
IIC.
APPLICABLE REQUIREMENTS
CSA C22.2 No. 60079-0:2011 - Explosive atmospheres. PART 0: Equipment - General requirements.
CSA C22.2 No. 60079-1:2011 - Explosive atmospheres. PART 1: Equipment protection of flameproof enclosures
“d” Second Edition.
CSA C22.2 No. 60079-7:2012 – Explosive atmospheres. PART 7: Equipment protection by Increased Safety ‘e”
CSA C22.2 No. 60079-11:2014 – Explosive atmospheres. PART 11: Equipment protection by Intrinsic Safety “i”
CSA C22.2 No. 60079-31:2012 - – Explosive atmospheres. PART 31: Equipment dust ignition protection by
enclosure “t”
CSA C22.2 No. 61010-1:12 - Safety Requirements for Electrical Equipment for Measurement, Control, and
Laboratory Use - Part 1: General Requirements
UL 61010-1:2
nd
Edition - Safety Requirements for Electrical Equipment for Measurement, Control, and
Laboratory Use - Part 1: General Requirements
UL 60079-0:2013 - Explosive atmospheres. PART 0: Equipment - General requirements.
UL 60079-1 - 2009 - Explosive atmospheres. PART 1: Equipment protection by flameproof enclosures “d”.
UL 60079-7:2008 – Explosive atmospheres. PART 7: Equipment protection by Increased Safety ‘e”
UL 60079-11:2013 – Explosive atmospheres. PART 11: Equipment protection by Intrinsic Safety “i”
UL 60079-31:2015 - – Explosive atmospheres. PART 31: Equipment dust ignition protection by enclosure “t”
MARKINGS
The manufacturer is required to apply the following markings:
