Biodex Medical Systems, Inc. © 2016 201
Detector Shield
.25 in. (6 mm) lead surrounding ionization detector, with top well opening.
Detector Bias
355 +/-5 volts
Environmental Operating Conditions
Temperature: 10 to 30°C
Humidity: 0 to 90% rh, non-condensing
For optimum performance, the Atomlab 500 should be operated in a normal laboratory
environment where the temperature and humidity are maintained for normal human comfort
and the ambient radiation level is low and constant.
Environmental Shipping And Stowage Conditions
Temperature: 0 to 40°C
Humidity: 0 to 90% rh, non-condensing
For optimum performance, the Atomlab 500 should be operated in a normal laboratory
environment where the temperature and humidity are maintained for normal human comfort
and the ambient radiation level is low and constant.
Physical Data
Display Unit Detector Unit
Size: 9.5" w x 12" h x 12" d 6" dia x 15.5" h
(24.13 x 30.48 x 30.48 cm) (15.24 x 39.37 cm)
Weight: 4.2 lb (1.9 kg) 38 lb (17.3 kg)
Power
This system uses an XP power supply for medical use, model #pdm60us15, or the alternate ICC
Nexergy (Pei Genesis) model MWA065015A-11A (modified).
Line Voltage
100 to 240 VAC, auto selectable by the power supply.
1.5 - 0.75 AMPS
Line Frequency
50/60 Hz
Detachable line cord. Built-in EMI filter and transient suppression.
WARNING: Before inserting or removing connectors turn system power OFF.
AVERTISSEMENT: Avant le fait d'insérer ou le fait d'enlever des connecteurs éteignent le
pouvoir de système.
Detector Cable
Length
Standard: 8 ft (2.438 m); custom cable lengths available up to 20 meters
