P1 Patient Monitor User’s Manual
4
less than 4 hours when it is turned off.
When the monitor is turned on, it is charged to 90% for less than 5
hours and 100% for less than 6 hours.
Turn off delay
5 min-15min（after the low battery alarm first occurs）
Note: when two batteries are equipped, internal CO
2
can not be equipped, but external
CO
2
plug-in module can be equipped.
A.5 Hardware Specifications
A.5.1 Display
Host display
Type Color TFT LCD
Size (diagonal) 5.5 inch
Resolution
720×1280 pixels
External display
P1+Docking station VGA display, resolution above 720*1280pixels
A.5.2 Mainframe LED
Alarm lamp
Cyan, yellow and red
Power indicating lamp
1 (Green/Orange)
When powered with AC, it lights green while turn on and off
the monitor.
When powered with battery, the orange light is on when the
battery is turned on, and no light is on when the battery is
turned off.
Battery charging
indicating lamp
1 (yellow), When charging, it is always on, and when it is fully
charged, the light goes out.
A.5.3 Audio indicating
Speaker
Give alarm tone (45-85dB), QRS tones;
Support PITCH TONE and multi-level tone modulation;
