P1 Patient Monitor User’s Manual
13-9
Scale
Set the 【Left Scale】 for arterial pressure.
Set the 【Right Scale】 for venous pressure.
Set the 【Grid】 of the overlapped waveform area.
Set the 【Wave Speed】 of the overlapped display waveform.
13.6. Calculating Cerebral Perfusion Pressure
The monitor can calculate the difference between mean arterial pressure (ART) and
the intracranial pressure (ICP). The difference is cerebral perfusion pressure, which is
labeled CPP. Therefore, the CPP value will be displayed on the screen only when the
ART and ICP are displayed at the same time.
13.7. IBP troubleshooting
This section describes problems you may encounter during using. You can refer to
the following table for troubleshooting. If the problem persists, please contact
maintenance staff.
NOTE: See D Alarm Message for physiological alarms and technical alarm
information.
Problem Solution
IBP parameter area and waveform
area cannot be found on the
interface
1. Check whether the display of IBP
parameters is set in the 【Screen Layout】
menu or not. For details, see 3.5.1 Setting
Parameters to be protected.
2. Check whether the IBP parameter switch is
turned on or not. For details, see 3.5.1 Setting
Parameters
3. Check the IBP cable, IBP sensor and
module are connected or not.
