P1 Patient Monitor User’s Manual
3-17
to your needs. If you select HI RES Display Mode, the main screen can display more
physiological parameter, waveform and quick keys. To set HI RES Display Mode, you
can follow the below steps:
1. Select 【 Main Menu 】 quick keyfrom the 【 System 】 column to select
【Maintenance】enter the maintenance password.
2. Select 【Other】 submenu.
3. Select 【Screen Display Mode】:
【Standard Mode】;
【HI RES Mode】.
The method of connecting to the external display is as follows:
1. Connect the Docking Station and the external display using the VGA cable.
2. Connect the external display to the AC mains and turn on the display.
3. Connect the P1 to the Docking Station.
NOTE：The external display can share the mouse or keyboard with the
monitor. If the mouses or keyboards are needed, connect them to the USB
connector of the Docking Station.
3.9. Shutting off the Monitor
Please follow the below steps to shut off the monitor:
1. Confirm that the patient monitoring is finished.
2. Disconnect the cables and sensors form the monitor.
3. Confirm that the monitoring data is stored or cleared.
4. Press the power switch for several second, the monitor interface will pop up the
shutdown dialog box, click OK to shutting off the monitor.
CAUTION：
Although not recommended, you can press and hold the power on/off switch
for 5 seconds to forcibly shut down the monitor when it could not be shut down
