P1 Patient Monitor User’s Manual
1-3
1.4. Measurement Modules (when using with Docking Station)
The plug-in modules are used to monitor the patient’s physiological parameters. The
monitor provides the following modules:
Modules Comments
SpO
2
module Support SpO
2
monitoring (Nellcor, Masimo)
CO
2
module Support Mainstream CO
2
(C8), Sidestream CO
2
(C1) monitoring
NIBP module Support NIBP module (Suntech)
1.5. Appearance
1.5.1. Main Unit
1.5.1.1. Front View

1. Display screen
2. Light induction: For example, when the environment is dark, the display brightness
can be automatically adjusted.
3. Alarm lamp
Alarm lamp with different color and flashing frequency indicates the level of
technical alarm and physiological alarm:
 High level alarm: the lamp quickly flashes red.
 Medium level alarm: the lamp slowly flashes yellow.
 Low level alarm: the lamp lights cyan without flashing.
4. Power indicating lamp
23
1
4
5
