P1 Patient Monitor User’s Manual
3-16
3.7.3. Setting the Timer
You can set each timer independently. To set the timer, follow this procedure:
1. Select the timer area to enter the
【
Timer
】
menu.
2. Set【Timer Type】:
【Normal】: The timer is timed according to the present 【Run Time】.
Stop timing when running time is reached.
【Cycled】: The timer cycles, that is, the timer counts according to the
preset 【Run Time】, and starts timing again after reaching the run time. The
timer area displays the number of timer cycles.
【Unlimited】: The timer displays the time elapsed since the timer was
started.
3. Set【Direction】.
4. Set【Run Time】.
5. Set【Reminder Volume】
. When the remaining time is 10 seconds, the monitor
issues a reminder tone and the timer flashes in red, prompting you that the run
time is to expire.
CAUTION：
Do not change timer settings when a timer is working.
Set【Direction】, 【Run Time】and【Reminder Volume】only for【Normal】
or【Cycled】.
3.8. Using the External Display
The P1 can be connected to an external display through the VGA connector of the
Docking Station. When the external display in connected, you can monitor a patient’s
either through the P1 or through the external display. The external display mirrors the
content of the P1 main screen.
When using the external display, you can set the display mode of the screen according
