P1 Patient Monitor User’s Manual
14-12
mixture is Helium, select【Helium】.
The Masimo sidestream CO
2
module supports automatic air pressure compensation
and automatic temperature compensation. Manual setting is not required under normal
conditions, but other gas interferences may exist in the gas circuit. In order to ensure
accurate measurement of Masimo module, the following compensations can be manually
set according to actual conditions:
——【O
2
Concentration】: Set the oxygen concentration. Can choose 0% ~ 100%,
the default value is 16%.
——【N
2
O Concentration】: Set the concentration of N
2
O. Can choose 0% ~ 100%,
the default value is 0%.
WARNING:
Please set the CO
2
corrections according to actual situation, otherwise, the
measured value may be inaccurate and away from actual value.
14.6.6. Operating mode
You can select the operating mode of the CO
2
module according to the actual
situation of the module. The operation steps are as follows:
1. Select the CO
2
parameter area or waveform area to enter the【CO
2
】menu.
2. Select【Setup】submenu.
3. Set【Operation Mode】.
Measure: Select measurement mode is required when measuring with the
CO
2
module.
Sleep:
When not using CO
2
for monitoring, it is recommended to set the
CO
2
module to sleep mode to increase the life of the CO
2
module.
14.7. Entering Intubation Status
When performing intubation during general anesthesia, you can enter the intubation
mode in order to reduce unnecessary alarms. To enter the intubation mode, follow this
procedure:
1. Select the CO
2
parameter area or waveform area to enter the【CO
2
】menu.
2. Select【Intubation Status】button.
