P1 Patient Monitor User’s Manual
6
Output impedance Rated 50
ECG analog signals output
Output signal range
-10V～+10V
Maximum
transmission delay
25 ms
Sensitivity 1V/mV±5%
PACE rejection /
strengthen
Has PACE rejection function
IBP analog signals output
Output signal range
-1V～+4V
Maximum
transmission delay
35 ms
Sensitivity 1V/100mHg±5%
Nurse call output
Output voltage range High level: 3.5~5V, providing a maximum of 10mA output
current;
Low level: <0.5V, receiving a maximum of 5mA input current.
Isolated voltage 1500 VAC
Signal type N.C., N.O., Pulse Output (optional);
Rise and drop time 1ms
Defibrillator synchronization signal output
Output impedance 50±10%
Maximum delay 25 ms (from R wave crest to pulse raise)
Amplitude High level: 3.5~5V, providing a maximum of 1 mA output
current;
Low level: ＜0.5V, receiving a maximum of 5 mA input current.
Pulse width 100ms±10%
Rise and drop time
＜1ms
Alarm output
