P1 Patient Monitor User’s Manual
8-11

CAUTION：
 【ECG 1】 is the key calculation lead; 【ECG 2】is the auxiliary calculation
lead. Only when the ECG 【Lead Type】 is 5/6/12 lead can you set【Multi-lead
Analysis】.
8.5.5. Setting ECG Waveform
8.5.5.1. Setting ECG Waveform Gain
If the ECG waveform is too small or clipped, you can change its amplitude by
selecting an appropriate gain setting. To do so, follow this procedure:
1. Select ECG parameter area or waveform area to enter the【ECG】menu.
2. Select【Gain】submenu.
3. Set the size of each ECG waveform. If you select【Auto】, the monitor
automatically adjusts the gain of the ECG waveforms.
8.5.5.2. Setting ECG Waveform Speed
To change ECG waveform speed, follow this procedure:
1. Select ECG parameter area or waveform area to enter the【ECG】menu.
2. Select【Setup】submenu.
3. Set【Wave Speed】.
8.5.5.3. Setting ECG Filter Mode
To set the ECG waveform filtering mode, follow this procedure:
1. Select ECG parameter area or waveform area to enter the【ECG】menu.
2. Select【Setup】submenu.
3. Set【Filter Mode】.
 【Diagnose】: Use when diagnostic quality is required. The unfiltered
ECG waveform is displayed so that changes such as notch on R-wave,
ST elevation or depression, etc.
 【Monitor】:Use under normal measurement conditions.
