www.biopac.com
BIOPAC Hardware | EL160 Series | Page 1 - 1 Updated: 3.20.2013
ELECTRODES
In selecting the application site for any style of electrode, care should be taken that:
1) Electrode site is dry and free of excessive hair.
2) Electrode is not placed over scar tissue or on an area of established erythema or with a lesion of any kind.
3) Skin is properly prepared. (Prepare the skin at the electrode site. Use the ELPAD to lightly abrade the skin
surface. Use a brisk dry rub to prepare the application site. Avoid excessive abrasion of the skin surface.)
EL160 GOLD CUP
Reusable gold cup electrode with 10 mm cup diameter and 1.2 m cable.
One electrode per package.
EL160 with black cable
EL160-R with red cable
EL160-W with white cable
The leadwire terminates in a standard Touchproof connector. Use with MEC Series
Module Extension Cables for MP Research Systems or SS1LA Touchproof Electrode
Lead Adapter for BSL System
s.
EL160-EAR – EAR CLIP ELECTRODES
This pair of gold-plated ear clip electrodes has 1.2 meter Teflon-insulated
leadwires
ending in standard Touchproof connectors.
EL160-EAR SPECIFICATIONS
Electrodes:
two
Material: Au Cup (gold plated discs)
Style: Ear Clip Electrodes
Leadwires: 1.2 meter Teflon-insulated leadwires
Connector: leadwires terminate in standard Touchproof connectors
Non-sterile
Reusable
