BIOPAC Hardware | Nerve Chambers | Page 1 - 2 Updated: 3.27.2013
NERVE CHAMBERS: NERVE1 AND NERVE2
These acrylic, desktop Nerve Chambers have 15 stainless steel pins for recording and stimulating a variety of
different nerve preparations. Each stainless steel pin is spaced 5mm apart to provide a variety of recording and
stimulating configurations. The sockets accept 2 mm pin plugs.
NERVE1 and NERVE2 Comparison
Feature NERVE1 NERVE2
Deep Reservoir (35mL)—contain Ringers or other solutions x x
Drain—facilitate extended viability of the preparation. x x
Agent Well — add compounds (ether, dry ice, etc.) 1.4cm x 2cm x 2cm (h x w x l) x x
Lid—enclose the preparation. 50mm thick x --
Valve & hose—flush and drain options x --
NERVE1 – WITH AGENT WELL AND LID
NERVE1 cha
m
b
e
r includes:
Deep Reservoir (35 mL) for containing Ringers or other solutions
Drain (with valve & hose) to facilitate extended viability of the preparation
Agent Well for adding compounds (such as ether or dry ice)
Lid to enclose the preparation when the protocol requires it.
NERVE2 – STANDARD NERVE CHAMBER
NERVE1 chamber includes:
Deep Reservoir (35mL) for containing Ringers or other solutions.
Drain (with valve & hose) to facilitate extended viability of your
preparation.
NERVE CHAMBER SPECIFICATIONS (NERVE1/NERVE2)
Pins: 15, stainless steel
Spacing: 5 mm
Sockets: accepts 2 mm pin plugs
Reservoir: holds 35 mL (or use drain/valve)
Dimensions: 4.5 cm x 7 cm x 14 cm (H x W x L)
Agent well: (NERVE1 only) 1.4 cm x 2 cm x 2 cm (H x W x L)
NERVE2
Lid: (NERVE1 only) 50 mm thick
Related components:
STM100C Stimulator Module
STMISO Series Stimulator Modules
MCE100C Micro-electrode Amplifier
ERS100C Evoked Response Amplifier
EMG100C Electromyogram Amplifier
