Keying using ATEM Switchers
DVE border parameters
The upstream key LCD menu is used to adjust the border parameters for the DVE and picture
in picture.
Border Enables or disables the border.
Color This item appears greyed out because it is not a setting, but rather
an indicator to show you the selected border color. You can use this indicator
to quickly verify the color of the DVE border.
Hue Changes the border color. The hue value is a location on the color wheel.
Saturation Changes the intensity of the border color.
Luminance Change the brightness of the border color.
Style Sets the bevel style for the DVE border.
Outer Width Adjusts the outside width of the border.
Inner Width Adjusts the inside width of the border.
Outer Soften Outside softness adjusts the outside edge of the border, the edge that touches
the background video.
Inner Soften Adjusts inside softness. This softness parameter adjusts the inside edge of the
border, the edge that touches the video.
Border/Shadow Opacity Opacity adjusts the transparency of the border and shadow, use this setting to
create interesting colored glass borders.
Bevel Position Adjusts the position of the 3D bevel on the border.
Bevel Soften Bevel softness adjusts the overall softness of the 3D border. A high value for
this parameter will result in a rounded or beveled border.
DVE shadow light source parameters
Enable Shadow
Enables or disables the drop shadow.
Angle
Adjusts the direction of the light source on the DVE or picture in picture.Both the
border and drop shadow, if available, are affected by changes to this setting.
Altitude
Adjusts the distance of the light source from the DVE or picture in picture. Both the
border and drop shadow, if available, are affected by changes to this setting.
142
