16.7
•
Remove the fastenings (arrows) for the bracket
•
Press down fuel tank
•
Use hoist to raise until the fuel tank can be re-
moved from the side
When installing:
•
While installation is basically a reversal of the re-
moval process, careful attention should be di-
rected toward the following operations:
e
Attention:
Ensure that the fuel tank supports (arrows) (foam
rubber) are positioned correctly!
Make sure there is adequate clearance to the right-
side tunnel panel!
X
Torque specification:
Bracket, fuel tank to frame ............................. 9 Nm
Bracket, washer fluid reservoir/ABS ECU
to frame ......................................................... 9 Nm
16 12 008
Replacing fuel filter
–Open the seat
– Remove left service cover
a
....................................................See Group 46
d
Warning:
Comply with safety precautions when handling or
working with fuel!
•
Remove fastener (arrow)
C1160070
C1160151
C1160080
