Bosch CB 28 - Product Description; Intended Use; Scope of Delivery; Special Accessories

1 689 989 212 2014-10-31| Robert Bosch GmbH
Product description | 1 687 010 496 | 15 en
3. Product description
3.1 Intended use
This accessory kit contains clamping accessory and
connection accessories for the testing of common rail
pumps CB 28 (hereinafter referred to as CB 28) in con-
junction with the EPS 815, with lubricating oil supply
and tester set CRS 845H.
3.2 Scope of delivery
Designation Part number
Fixing flange (for flange  85 mm) with
4 blind holes for hexagon bolt (4 x M10 x 30
ISO 4017-8.8)
1 685 720 356
Hexagon bolt (4 x M10 x 30 ISO 4017-8.8) 2 911 061 761
Washer (4 x DIN 125-A10.5-ST) 2 916 011 018
Coupling half (D=24.8, M18 x 1.5) 1 686 430 059
Mounting sleeve for coupling half 1 680 506 040
Mounting wrench for coupling half 1 687 951 030
Exhaust gas sampling hose (suction line
with flow restrictor D = 2.4 mm)
1 680 712 367
Exhaust gas sampling hose (supply) 1 680 712 202
Union nut (2 x A2L15 DIN 3870) 2 915 101 009
Cutting ring (2 x 15 DIN 3861) 2 916 673 008
Inlet union (2 x M14X1.5/ AD15/ 24°) 1 683 385 056
Test adapter (M14 x 1.5 / plug-in hose nip-
ple)
0 986 613 091
Inlet union screw (2 x 10(3-4) DIN
7643-9SMNPB2)
2 911 201 703
Flat sealing ring (8 x A14X18 DIN 7603-CU) 2 916 710 609
Threaded piece (M16x1.5 / M14x1.5) 2 413 359 003
Flat sealing ring (2 x A16X20 DIN 7603-CU 2 916 710 611
Threaded socket (M10x1, ISO 8434-1-L10) 1 683 356 133
Hose line (return) 1 680 712 373
Flat sealing ring (3 x DIN 7603 A 10 X 13.5
-Cu
2 916 710 605
Screw clamp (10 - 16 mm) 1 681 314 078
Hydraulic hose (2 x G 1/8 - coupling) 1 680 712 327
CD-Testdata Vers. 2014/C or higher 1 687 370 318
i The order numbers in the 'Scope of delivery' chapter
are only for information.
3.3 Special accessories
Designation Part number
Pressure gauge 0–1600 kPa (0 – 16 bar) 0 986 613 102
Pressure gauge -100–500 kPa (-1 – 5 bar) 0 986 613 103
Parts set for drain valve (2 x) 0 986 615 075
3.4 Prerequisites
R EPS 815
R Test set CRS 845H (1 687 002 845).
R Software EPS 945, Version 4.35 or higher
R Operating knowledge on the EPS 815 with lubricat-
ing-oil supply and on tester set CRS 845H.
R Good knowledge of the mode of operation of com-
mon rail pumps.
3.5 Installing the EPS 945 software
1. Insert the "EP software" CD in the DVD/CD drive.
 Installation of the software then starts automat-
ically.
 The dialog box, "Select Setup Language", is dis-
played.
2. Comply with the instructions and install the soft-
ware.
