Reference Information
Service Specifications
13
1
HP 40 40 H.O. 50 60
Oil System
Lubricant – Preferred Lubricant
–Acceptable Lubricant
Evinrude/Johnson XD100, XD50, XD30; or
NMMA TC-W3 certified
Capacity 2 qt. (1.9 l)
Cooling System
Thermostat 143°F (62°C)
Maximum Temperature 212°F (100°C)
Water pressure 12 to 14 psi @ 5000 RPM
Electrical System
Minimum Battery Requirements 640 CCA (800 MCA) or 800 CCA (1000 MCA) below 32° F (0° C)
Alternator
25-Amp fully regulated. Refer to Installation and Predelivery Guide for multiple bat-
tery applications.
Tachometer Setting 6 pulse (12 pole)
Engine Fuse P/N 967545 – 10 A
Ignition System
Type Capacitor Discharge
Firing Order 1-2
Ignition Timing EMM Controlled
RPM Limit in Gear 6250
RPM Limit in Neutral 1800
Crankshaft Position Sensor Air
Gap
Fixed
Spark Plug
Refer to Emission Control Information Label
Champion
†
QC10WEP @ 0.028 ± 0.003 in. (0.71 mm)
Gearcase
Gear Ratio 11:32, 0.34, 2.90:1
Lubricant
– Capacity
Evinrude HPF Pro Lubricant
22 fl. oz. (650 ml)
Shift Rod Height 20 in. (L) Models: 21.38 (543 mm) ± one-half turn
Shift Cable Stroke 1.125 to 1.330 in. (28.6 to 33.8 mm) measured between NEUTRAL and FORWARD
Trim & Tilt System (Full Featured)
Lubrication Evinrude/Johnson Power Trim & Tilt Fluid, P/N 775612
Fluid Capacity 15.2 fl. oz. (450 ml)
Trim Range 0° to 15°
Tilt Range 16° to 65°
