BRP E-TEC EVINRUDE - Service Chart

130
Fuel System
Service Chart
Service Chart
2-Cylinder Models: Injectors, Vapor Separator, Fuel Pump
F
24-36 in. lbs.
(2.7-4.0 N·m)
24-36 in. lbs.
(2.7-4 N·m)
60-84 in. lbs
(7-9.5 N·m)
60-84 in. lbs
(7-9.5 N·m)
H
S
H
F
60-84 in. lbs
(7-9.5 N·m)
A
A
5 ft. lbs.
(7 N·m)
24-26 Ft. lbs.
(33-35 N·m)
10 ft. lbs.
(14 N·m)
1
2
3
002154A
Tighten in 3 stages
A Triple-Guard Grease
B Gasket Sealing Compound
C Adhesive 847
E Red Ultra Lock
F Blue Nut Lock
H Outboard Engine Lubricant
S STP
†
Oil Treatment
X see Service Manual
