Recoil Starter Removal
13
Recoil Starter Removal
Remove the clamp holding the oiling system wir-
ing harness.
Remove the three starter housing screws and
washers.
Lift starter housing from outboard.
Remove three screws and remove starter ratchet
from flywheel.
Recoil Starter Disassem-
bly
Pull the starter rope out far enough to tie a slip
knot in the rope. Remove the end of the starter
rope from the handle anchor and remove the han-
dle. Release the slip knot and ease the rope back
in until the rewind spring is fully unwound. If nec-
essary, remove the starter handle bracket from the
starter housing.
Remove the rope guide and pulley support from
the starter housing.
 WARNING
Turn the key switch OFF, and disconnect the
Crankshaft Position Sensor (CPS), to prevent
accidental starting while servicing.
1. Clamp
2. Starter housing screws (3)
002515
1. Ratchet
006483
1
2
2
2
1
 WARNING
Wear safety glasses while disassembling and
assembling manual starters because of
rewind spring tension.
1. Slip knot
2. Rope anchor
007853
1. Rope guide
2. Pulley support
007854
2
1
1
2
