Powerhead
Piston Pin Retainer Tool
Piston Pin Retainer Tool
Use the drawing below to modify a pair of needle nose pliers to remove piston pin retaining rings.
0.09375 in
2.38125 mm
0.03125 in
0.79375 mm
0.03125 in
0.79375 mm
0.0625 in
1.5875 mm
010457
0.0625 in
1.5875 mm
NOT to Scale
