BRP E-TEC EVINRUDE - Exhaust Relief Muffler; Exhaust Water Valve (40 H.O.;60 HP 2-Cylinder Models)

251
Midsection
Exhaust Housing, 2-Cylinder Models
11
Remove the exhaust housing.
Exhaust Water Valve
(60 HP 2-Cylinder Models)
Disconnect water valve electrical connector.
Remove screws and bracket holding valve to
exhaust housing.
Remove tie straps and disconnect water valve
hoses (3) from exhaust housing.
Check that all water passages are clear.
Install hoses to fittings on exhaust housing.
Place water valve and bracket in position.
Apply Nut Lock to screws, install and tighten 60 to
84 in. lbs. (7 to 9.5 N.m).
Exhaust Relief Muffler
Remove exhaust relief muffler cover to inspect fil-
ter element. Clean or replace as needed.
Exhaust Housing
005069
1. Electrical connector
2. Inlet hose
3. Outlet hose
004293
2
3
1
1. Fitting, water passage
004300
1. Exhaust water valve screws
004293
1. Exhaust relief muffler cover
004301
1
1
1
1
